Heating :-
Superior heating system. The heat is Well distributed
throughout the oven. Specially designed heaters (Ceramic
Bobbin enclosed in SS tubes) are fixed Inside the Oven
on top and Bottom. The heaters are easily replaceable.
Temp
Controls :-
Top and bottom heat can be controlled Independently by
Thermostats or Digital Temp. Controller with indicator
with Fe-Con sensor.
Power
Supply :-
440 V, 3-0, 4-wire system.
Loading
Decks :-
Wire Mesh Tray of aluminum, 22 SWG, duly anodized and
matt finished.
Performance
:-
The oven can maintain temperatures up to 300°C.
Temp. Range
:-
50°C to 300°C with an accuracy of +2°C.
Illumination :-
Provided by a bulb on the side wall, covered with
toughened glass.
Finish :-
The oven is finished in Nikel Grey or any colour of your
choice.
|
Inner Size: L x W x H |
Tray Size |
Capacity |
Rating |
No. of Tray
|
|
30" x 18" x 8" |
12" x 12" x 2" collar,
without hole. |
a. Single Decker
b. Double Decker
c. Triple Decker |
3 Kw
6 Kw
9 Kw |
2 Trays.
4 Trays
6 Trays. |
|
42" x 42" x 8" |
19" x 19" x 2" collar,
without hole. |
a. Single Decker
b. Double Decker
c. Triple Decker |
7 Kw
14 Kw
21 Kw |
6 Trays
12 Trays
18 Trays |
|
Optional :-
-
Aluminum Tray, 22G, matt finished and anodized of size
12” x 12” x 2” collar, without hole
-
Aluminum Tray, 22G, matt finished and anodized of size
19” x 19” x 2” collar, without hole
|
