HOSPITAL EQUIPMENTS - GMP GC - 1048 IVF Laboratory Warming

Laboratory warming plates are mainly used for maintaining the temperature of sperm samples during analysis and for keeping follicular fluid and oocytes at 37°C during oocyte pickup. They are frequently combined with warming blocks for perfect adjustment to dishes or tubes. Heat is passively transmitted to any type of warming blocks without any loss. Warming plates can also be used to pre-heat instruments or disposables or for seamless integration into table plates The anode treated aluminum surface is extremely resistant. The temperature range is between ambient and 55°C with an accuracy of ± 0.2°C.

Advantages:

• Highly accurate temperature control by Microprocessor based PID Auto tuned Digital Temperature control with Pt-100 RTD as Thermocouple Sensor with SSR Control as output

• Robust and extremely durable

• Adjustable temperature

• 2 models to choose from: 300 .

• Easily transportable

• Separate control unit

• Material: AL thick plate with Epoxy Matt Black powder coated Finished
• Cable length: 2.5 m
• Power Supply: 230v, 50 Hz with mains cord of 2
• Sandwiched type one piece Low watt Heater is embedded in to the Warmer Plate for uniform heating.
• RTD 3 wire PT-100 Thermocouple temperature probe is used for precise measurement of temperature.
• MCB & Safety Fuse with Earthling connection is incorporated with the UNIT as a precautionary safeguard.
• Resolution: 0.1*C. Accuracy: +/- 0.5*C. Uniformity of Temperature: +/- < 1% of FSD.
• Maximum Temperature & Parameter Lock facility for Microprocessor Digital Temp Controller is available.
• Dual Display of temperature for “SET” value (Lower Green Display) & “PV” ( Present Value in Red Display) for ease of viewing.

Warming Plate: Size: 450mm x 300mm x 12.5mm ( L x W x Thickness )

NOTE: We can make any size of IVF Warmer plate as per requirement of customers.

NOTE: You will be offered 15% Discount on the quoted price on ad-hoe basis. Please go through & let us know your valuable reply for further proceedings.
